TR-H2B5 3.6

Technical specifications

WDR:

DWDR 105 dB

Maximum video output resolution:

1920x1080

Image sensor:

1/3" CMOS

Power supply:

12V DC

Sensitivity(Lux):

0,01

Ingress protection:

IP67

Dimensions (mm):

73x76x157

Working temperature, C°:

-30...+60
Overview

TRASSIR TR-H2B5 (3.6mm)


This analog camera is suitable for outdoor use regardless of season or installation location: the enclosure is protected against moisture and dust in accordance to the IP67 norm, operating temperatures: -30 °C to +60 °C. Compatible with AHD, HD-CVI, HD-TVI data transfer formats: transmits an uncompressed 2 MP video signal via coaxial cable over a distance of up to 500 m (1,000 ft) at a speed of 25 frames per second. Features noise reduction (2D DNR) and digital image processing (DWDR) to suppress the effect resulting from contrasting scene illumination.


Resolution by format:


  • AHD — 2 MP.

  • HD-CVI — 2 MP.

  • HD-TVI — 2 MP.

  • PAL — 960H.


Basic specifications:

TR-H2B5 (3.6 mm) is built on a 1/3" CMOS sensor with 0.01 lux sensitivity at f/1.2. Equipped with a 3.6 mm fixed focal length lens, horizontal field of view of 82°, vertical field of view of 45°. Supports day/night mode with a mechanical infrared cut-off filter (in conditions where light is sufficient, it standardizes the color rendition). Ideal for night surveillance: equipped with IR illumination with a range of 25 m (82 ft). Power supply: 12 V DC. Current consumption: 700 mA. Size: 157 × 73 × 76 mm. Weight: 650 g.
