TRASSIR NeuroStation Compact RE AnyIP 8

Technical Specifications

Maximum internal storage:

2

Resolution of cameras (max):

No limits

IP video input:

16

Bitrate (Mb/sec):

640

Power supply:

AC 220

Weight Net (kg):

6.8

Video output:

D-SUB, HDMI

Power supply, V:

AC 220

Dimensions (mm):

482x89x390

Power consumption, Watt:

500

Working temperature, C°:

+10...+30

Network interfaces:

RJ-45

Video compression:

H.265 | H.265+ | Н.264 | MPEG4 | MJPEG

USB 3.0:

3
Overview
TRASSIR NeuroStation Compact RE AnyIP 8
The IP video recorder is designed for  16 IP cameras (8 AnyIP licenses included)

Equipment:

  • Video recorder (assembled and packaged).
  • Mouse (USB)
  • Power cable
  • Product data sheet
  • Warranty card
  • DVR User Manual
  • System board user manual (in English)

Basics:

TRASSIR NeuroStation Compact RE Equipped with a Gigabit RJ-45 network port, HDMI and D-SUB video outputs, two SATA interfaces for HDD 3.5 "of any capacity, two USB 3.0 and one USB 2.0 on the rear panel, two USB 2.0 on the front, PS / 2 for a mouse and keyboard, audio-in-out Supports H.265, H.265 +, H.264, MPEG4, MJPEG codecs (depending on the IP camera).

The interfaces are represented by an RJ-45 network port with support for power over twisted pair, audio in / out and a built-in microphone, a connector for a power supply (not included in the package), a slot for a microSD card with a capacity of up to 128 GB. Power supply - DC 12V / PoE. In the maximum load mode, the power of the camera does not exceed 8.8 W. Dimensions - Ø116.00 × 90.91 mm, net weight - 520 g.
