TR-D2253WDZCL7 2.7-13.5
Technical specifications
Audio:
Built-in microphoneAudio-in
Audio-out
WDR:
RWDR 120 dBFrame rate:
25Electronic shutter speed:
1/2 ~ 1/1 000 sIR range:
70mDigital noise Reduction:
3D DNRCorridor mode:
YesResolution:
5MPForm factor:
BulletWi-Fi:
-Maximum video output resolution:
2880x1632Image sensor:
1/2.7" CMOSBitrate (Mb/sec):
8Power supply:
12V DCLens (mm):
2.7 - 13.5 (motorzoom)Net Weight (kg):
0.635Sensitivity(Lux):
0,0015Local storage:
microSD up to 128 GBIngress protection:
IP67Case material:
MetalLightning protection:
TVS 4000VDimensions (mm):
234.3 x 77.5 x 73.4Power consumption, Watt:
7.4Working temperature, C°:
-40°C ... +60°CDay/Night Mode:
FTCVideo compression:
Н.265+ / Н.265 / H.264Overview
5 MP (2880×1632) shock-resistant (IK08) IP camera TRASSIR TR-D2253WDZCL7 2.7–13.5 is adapted for outdoor use at any time of the year and day: IP67 protection against moisture and dust, operating temperatures from –40 °C… + 60 °C, lightning protection - TVS 4000 V, range of the integrated backlight - 70 m.
Functionality
Software motion detection, people, faces, cars.
Perimeter Guard: Virtual Line Crossing Detection.
Area control: detection of intrusion into the zone, exit from the zone.
Behavior Analysis: Loitering Detection.
People counting.
Built-in microphone.
WDR 120dB - Minimizes the effect of different contrast lighting on image quality.
3D DNR - spatial noise reduction.
Corridor Mode - Supports vertical resolution with a 9:16 aspect ratio.
Defog - increase the contrast to eliminate the effect introduced by fog, smoke.
ROI - fixing on the selected area and a parallel decrease in resolution in other parts of the frame.
BLC - backlight compensation.
Frame rate - 25 fps, bit rate - 8 Mbps
Compression H.265+, H.265, H.264.
Basics
TR-D2253WDZCL7 2.7–13.5 is equipped with a motorized lens with a focal length of 2.7 ~ 13.5mm, a horizontal angle of view of 103° ~ 33°, a vertical angle of 56° ~ 19°. Interfaces: RJ-45, audio input, audio output, alarm input and output, slot for microSD memory card up to 128 MB, power connector. Power supply - DC 12 V, PoE. The maximum power consumption is 8 watts. Size - 234.3 × 77.5 × 73.4 mm. Net weight - 635 g.
Functionality
Software motion detection, people, faces, cars.
Perimeter Guard: Virtual Line Crossing Detection.
Area control: detection of intrusion into the zone, exit from the zone.
Behavior Analysis: Loitering Detection.
People counting.
Built-in microphone.
WDR 120dB - Minimizes the effect of different contrast lighting on image quality.
3D DNR - spatial noise reduction.
Corridor Mode - Supports vertical resolution with a 9:16 aspect ratio.
Defog - increase the contrast to eliminate the effect introduced by fog, smoke.
ROI - fixing on the selected area and a parallel decrease in resolution in other parts of the frame.
BLC - backlight compensation.
Frame rate - 25 fps, bit rate - 8 Mbps
Compression H.265+, H.265, H.264.
Basics
TR-D2253WDZCL7 2.7–13.5 is equipped with a motorized lens with a focal length of 2.7 ~ 13.5mm, a horizontal angle of view of 103° ~ 33°, a vertical angle of 56° ~ 19°. Interfaces: RJ-45, audio input, audio output, alarm input and output, slot for microSD memory card up to 128 MB, power connector. Power supply - DC 12 V, PoE. The maximum power consumption is 8 watts. Size - 234.3 × 77.5 × 73.4 mm. Net weight - 635 g.
Documentation
TR-D2253WDZCL7_passport_en.pdf
