TR-D8121IR2 v6 2.8

Technical specifications

Audio:

Built-in microphone

WDR:

RWDR 120 dB

Resolution:

2MP

Form factor:

Sphere

Wi-Fi:

-

Maximum video output resolution:

1920x1080

Image sensor:

1/2.7" CMOS

Bitrate (Mb/sec):

8

Power supply:

DC 12 V, PoE

Lens (mm):

2.8

Net Weight (kg):

0.38

Sensitivity(Lux):

0,005

Ingress protection:

IP66

Dimensions (mm):

Ø92.8x92.2

Power consumption, Watt:

6.3

Working temperature, C°:

-40…+60

Day/Night Mode:

Mechanic IR-filter

Network interfaces:

RJ-45
Overview

TRASSIR TR-D8121IR2 v6 (2.8 mm)

2 MP (1920 × 1080) IP-camera is designed taking into account the conditions of round-the-clock year-round outdoor operation in places out of sight of security personnel: the metal case is protected from mechanical impacts according to the IK10 code, from moisture and dust - according to the IP66 standard, operating temperatures from –40 ° C… +60 ° C, lightning protection - TVS 4000 V, range of integrated backlighting - 25 m.


Functionality:

  • - Built-in microphone.
  • - Detection of people.
  • - Motion detection.
  • - Area control (detection of intrusion / exit from the zone).
  • - Detection of crossing the virtual line.
  • - WDR 120 dB - minimizes the effect of changes in light level on image quality.
  • - 3D DNR - spatial noise reduction.
  • - Supports vertical resolution (corridor mode) with an aspect ratio of 9:16.
  • - Defog - Automatically removes blur introduced by fog or smoke by enhancing the contrast.
  • - BLC - Backlight Compensation.
  • - Day / night mode with ICR, with sufficient illumination to block the rays of the infrared range to normalize color reproduction; in the dark, the filter is shifted away from the matrix so that its sensitivity increases and the backlight can work.
  • - Compression with H.265 +, H.264 +, H.265, H.264 codecs.
  • - Broadcast speed - 25 fps.

Basics:

TR-D8121IR2 v6 (2.8 mm) is equipped with a 2.8 mm fixed focal length lens, 82 ° horizontal field of view, 44 ° vertical field, F / 1.8 aperture. Equipped with an RJ-45 network port, a microSD slot with a capacity of up to 128 GB, a power connector. Power Supply - 12V DC or PoE. The maximum power consumption is 6.3 W. Dimensions - Ø92.8 × 92.2 mm. Weight - 380 g.
