TRASSIR MiniNVR 2216R-16P

Technical specifications

Number of HDD:

8

Bitrate (Mb/sec):

256

Power supply:

AC 220 V

Net Weight (kg):

3.0

Video output:

HDMI, D-SUB (VGA)

Dimensions (mm):

382×332×47 мм

Power consumption, Watt:

280

Working temperature, C°:

0 °C… +30 °C

Network interfaces:

1

Video compression:

H.265, Н.264
Overview

TRASSIR MiniNVR 2216R-16P is designed for 16 IP cameras with a resolution of up to 12 megapixels. Equipped with video outputs - HDMI and D-SUB (VGA), Gigabit RJ-45 network port, independent Gigabit PoE RJ-45 ports (for supplying power to cameras simultaneously with data transmission - up to 13 W per port), SATA for two hard drives 3.5 "form factor, USB 2.0 and USB 3.0, audio input and output. Supports H.265 and H.264 codecs. Supplied with Linux-based TRASSIR OS. Recording resolution - up to 12 megapixels. Output resolution: up to 8 megapixels - HDMI, up to 2 Mp - VGA Bit rate - 256 Mbps: 8 Mbps for each main stream, 1 Mbps for additional stream.


Equipment:


  • Video recorder (assembled and packaged)

  • Mouse (USB)

  • Power supply 12 V (5 A)

  • Power cable

  • Rack Mount Kit with Screws

  • Screws for securing hard drives

  • Technical certificate


Basics:

Power supply - AC 220 V, power - 280 W. Dimensions - 382 × 332 × 47 mm, gross weight - 3.8 kg. Operating temperatures - 0 ° C ... +30 ° C.
