TR-D4S1 v3 3.6

Technical specifications

WDR:

RWDR 105 dB

IR range:

Up to 20

Resolution:

4MP

Form factor:

Sphere

Wi-Fi:

-

Maximum video output resolution:

2560x1440

Image sensor:

1/3" CMOS

Bitrate (Mb/sec):

up to 8Mbps

Power supply:

PoE (802.3af) / 12V DC

Lens (mm):

3.6

Net Weight (kg):

0.205 / 0.3

Sensitivity(Lux):

0.005Lux (F1.8)

Dimensions (mm):

Ø109.98 x 98.50

Power consumption, Watt:

DC: 3.2W PoE: 4.7W

Working temperature, C°:

-10°C … +50°C

Day/Night Mode:

Mechanical ICR

Video compression:

Н.265+ / Н.265 / H.264
Overview

The indoor 4 MP (2560×1440) IP Camera TRASSIR TR-D4S1 v3 3.6 is suitable for night surveillance, equipped with IR illumination with a range of 20 meters. It supports detection of people, motion, virtual line crossing, and intrusion into the area, as well as protocols TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, UpnP, SMTP, and ONVIF.


Functionality:

· WDR 105 dB: Minimizes the impact of lighting variations on image quality.

· 3D DNR: Suppresses spatial noise.

· Defog: Enhances contrast to neutralize blurring caused by fog.

· BLC: Compensates for backlighting.

· Day/Night Mode with ICR: In sufficient light, the filter refracts IR rays to normalize color reproduction, while in darkness, it mechanically shifts away from the sensor to increase its sensitivity.

· Compression: H.265+, H.265, and H.264.

· Transmission speed: 25 fps. Bitrate: 8 Mbps.


Basics:

The TR-D4S1 v3 3.6 is based on a 1/3" CMOS sensor with a sensitivity of 0.005 lux. It comes with a fixed focal length lens of 3.6 mm, providing a horizontal viewing angle of 77° and vertical viewing angle of 42°. Power options include DC 12 V or PoE. It operates within a temperature range of –10 °C to +50 °C, with a maximum power consumption of 4.7 W. Its dimensions are Ø110.0×98.5 mm, and it weighs 205 g.
