TR-D2S1 v2 3.6

Technical specifications

WDR:

RWDR 105 dB

Resolution:

2MP

Form factor:

Sphere

Wi-Fi:

-

Maximum video output resolution:

1920x1080

Image sensor:

1/2.9" CMOS

Bitrate (Mb/sec):

8

Power supply:

DC 12 V, PoE

Lens (mm):

3.6

Net Weight (kg):

0.205

Sensitivity(Lux):

0,005

Ingress protection:

None

Dimensions (mm):

Ø110x93.2

Power consumption, Watt:

2.4

Working temperature, C°:

-10…+50

Day/Night Mode:

Mechanic IR-filter

Network interfaces:

RJ-45
Overview

TRASSIR TR-D2S1 v2 (3.6 mm)

2 megapixel (1920 × 1080) IP-camera is equipped with IR illumination with a range of 20 m - for night video surveillance. Designed for indoor use.


Functionality:

  • - Detection of people.
  • - Motion detection.
  • - Detection of crossing the virtual line.
  • - Area control (detection of intrusion / exit from the zone).
  • - WDR 105 dB - Reducing the influence of changes in the level of illumination on the image quality.
  • - 3D DNR - spatial noise reduction.
  • - Corridor Mode - Supports 9:16 vertical resolution.
  • - Defog - enhances contrast to minimize the effect of fog and smoke.
  • - BLC - Backlight Compensation.
  • - The video stream speed is 25 frames per second.
  • - Compression with H.265 + and H.264 +, H.265 and H.264 codecs.
  • - Day / night mode with ICR: in sufficient light, the filter refracts IR rays, optimizing color rendition, and in the dark it is mechanically shifted away from the matrix to increase its sensitivity and backlight operation.
  • - Bitrate - 8 Mbps.

Basics:

TR-D2S1 v2 (3.6 mm) is built on a 1 / 2.9 "CMOS sensor with progressive scanning, 0.005 lux sensitivity. Equipped with a 3.6 mm fixed focal length lens, horizontal viewing angle 81 °, vertical viewing angle - 44 °. Power supply - DC 12 V or PoE Maximum power consumption - 2.4 W. Size - Ø110.0 × 93.2 mm Weight - 205 g Operating temperatures from –10 ° C… +50 ° C.
