TR-D4D5 3.6

Archive

Technical specifications

WDR:

DWDR 105 dB

Resolution:

4MP

Maximum video output resolution:

2688x1520

Image sensor:

1/2.7" CMOS

Bitrate (Mb/sec):

8

Power supply:

DC 12 V, PoE

Lens (mm):

3.6

Net Weight (kg):

0.295

Sensitivity(Lux):

0,005

Ingress protection:

IP66

Dimensions (mm):

Ø95x63

Power consumption, Watt:

6.8

Working temperature, C°:

-40…+60

Day/Night Mode:

Mechanic IR-filter

Network interfaces:

RJ-45
Overview
New!
Budget dome 4MP IP-camera with a variofocal lens.

1/2.7" CMOS sensor, sensitivity: 0.003 Lux (F1.3) / 0 Lux (IR on), 4MP (2688x1520) resolution @15fps, Day/Night mode (mechanical ICR), 2.7-13.5 mm lens, H.265 codec supported, D-WDR, 3D-DNR, BLC, Defog, 12V DC, -10°C ... +50°C, TVS 4000V, IR range up to 25m
