TR-D4B5 v3 3.6

Technical specifications

WDR:

RWDR 105 dB

IR range:

Up to 30

Resolution:

4MP

Form factor:

Bullet

Wi-Fi:

-

Maximum video output resolution:

2560x1440

Image sensor:

1/3" CMOS

Bitrate (Mb/sec):

up to 8Mbps

Power supply:

PoE (802.3af) / 12V DC

Lens (mm):

3.6

Net Weight (kg):

0.39 / 0.49

Sensitivity(Lux):

0.005Lux (F1.8)

Ingress protection:

IP67

Dimensions (mm):

152.1 x 68.3 x 62.9

Power consumption, Watt:

DC: 4.0W PoE: 4.9W

Working temperature, C°:

-40°C … +60°C

Day/Night Mode:

Mechanical ICR

Video compression:

Н.265+ / Н.265 / H.264
Overview

The 4 MP (2560×1440) IP Camera TRASSIR TR-D4B5 v3 3.6 is designed for outdoor use, enduring direct exposure to precipitation year-round. Its metal housing complies with the IP67 standard for dust and moisture protection, with an operational temperature range from –40 °C to +60 °C, and surge protection up to 4000 V. It is suitable for night surveillance with built-in IR illumination with a range of 30 meters.


Functionality:

· Detection: of people, motion, virtual line crossing, and zone intrusion.

· WDR 105 dB: reduces the impact of varying lighting conditions on image quality by selecting the optimal exposure within 105 dB.

· 3D DNR: noise reduction.

· Defog: eliminates blurriness caused by fog or smoke in the scene.

· BLC: compensates for backlighting.

· Day/Night Mode with a mechanical IR filter.

· Compression: H.265+, H.265, and H.264.

· Transmission speed: 25 fps. Bitrate: 8 Mbps.

· Supports protocols: TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, UpnP, SMTP, ONVIF.


Basics:

The TR-D4B5 v3 3.6 is based on a 1/3" CMOS sensor with a sensitivity of 0.005 lux. It comes with a fixed focal length lens of 3.6 mm, providing a horizontal viewing angle of 77° and vertical viewing angle of 42°, with an aperture of F/1.8. Power options include DC 12 V and PoE, with a maximum power consumption of 4.9 W. Its dimensions are 152.1×68.3×62.9 mm, and it weighs 390 g.
