TR-D2152ZIR3 2.8-8

Technical Specifications

WDR:

WDR (120 dB)

Maximum video output resolution:

2592x1944

Image sensor:

1/2.8" CMOS

Bitrate (Mb/sec):

8

Power supply:

DC 12 V, PoE

Lens (mm):

2.8-8

Weight Net (kg):

0.46

Sensitivity:

0,003

Ingress protection:

IP67

Dimensions (mm):

183.3x67.3x63.9

Power consumption, Watt:

5.8

Working temperature, C°:

-40…+60

Day/Night Mode:

Mechanic IR-filter

Network interfaces:

RJ-45
Overview

TRASSIR TR-D2152ZIR3

5 MP (2592 × 1944) IP-camera adapted for outdoor use at any time of the year: the metal case is protected from moisture and dust according to the IP67 standard, operating temperatures - –40 ° C ... +60 ° C, lightning protection - TVS 4000 V. For timely response to events and automation analytical functions are provided - detection of people and movement, detection of crossing a virtual line, control of the area for almost instant scaling of the picture in real time - 2.8 ~ 8.0 mm motorized lens with a horizontal viewing angle of 83 ° ~ 49 °, vertical - 61 ° ~ 37 °, F / 1.8 aperture, for night surveillance - IR illumination with a range of 35 m.


Resolution and broadcast speed:

5 MP - 15 fps.

4 MP - 20 fps.

3 MP - 25 fps.

2 MP - 25 fps.

2 MP - 25 fps.

1.3 MP - 25 fps.

1 MP - 25 fps.


Functionality:

  • - WDR 120 dB - minimizes the effect of different contrast lighting on image quality.
  • - 3D DNR - spatial noise reduction.
  • - Support for shooting in vertical resolution (corridor mode) with an aspect ratio of 9:16.
  • - Defog - Increases the contrast to eliminate the effect of fog or smoke in the scene.
  • - ROI - the function of freezing on the selected area and simultaneously reducing the resolution in small parts of the frame to optimize the bitrate.
  • - BLC - Backlight Compensation.
  • - HLC - local exposure masking.
  • - Day / night mode with ICR, with sufficient illumination blocking IR rays (in the dark it is shifted to increase the sensitivity of the matrix and the backlight).
  • - Compression with H.265, H.265 + and H.264 codecs.
  • - Built-in microphone.

Basics:

TR-D2152ZIR3 is equipped with an RJ-45 network port, a microSD slot with a capacity of up to 128 GB, and a power connector. Power Supply - 12V DC or PoE. The maximum power consumption is 5.8 W. Dimensions - 183.3 × 67.3 × 63.9 mm. Weight - 460 g.
